Silica Sand

Silica Sand



We are completely and specialized in offering exclusive range of superior quality Silica Sand that is acid soluble bridging agent. It is used in manufacturing of glass, fillers & extenders, abrasives & polishes, silica bricks, specialty coatings, ceramics rubber and optics, Silicate,& Construction Etc. It is processed keeping in mind international quality standards and is offered at very affordable price to the clients. Our sand is precisely processed under the supervision of our skilful professionals using the latest and advanced technology. Moreover, we provide this sand in various packaging options at reasonable prices.

MESH SIZE - [30*80], [24*60], [60*150] (MESH SIZE CAN BE SET AS PER YOUR REQUIREMENT)

Applications of Silica Sand



Glass: Silica is the major ingredient in virtually all types of glass. The principal glass products include containers (bottles and jars), flat glass (windows, mirrors, vehicle glazing etc.), lighting glass (light bulbs, fluorescent tubes, etc.), tableware (lead crystal, drinking glasses etc.), TV tubes and screens, decorative glass, fiber glass, optical glass and vacuum flasks.

Ceramics: Silica that has been ground to fine size is an ingredient of most clay bodies and is a major constituent of ceramic glazes. Typical everyday products include tableware, sanitary ware, ornaments and wall and floor tiles.

Filtration: Closely sized grades of silica sand is the principal filtration medium used by the water industry to extract solids from wastewater.

Sports and leisure: Silica sand is used for equestrian surfaces, in artificial turf, golf course root zones and dressings, football and cricket and other pitches and as play sands.

Chemical Production: Silicon-based chemicals are the foundation of thousands of everyday applications ranging from food processing to soap and dye production. In this case, SiO2 is reduced to silicon metal by coke in an arc furnace, to produce the Si precursor of other chemical processes. Industrial sand is the main component in chemicals such as sodium silicate, silicon tetrachloride and silicon gels.

Metal Production: Industrial sand plays a critical role in the production of a wide variety of ferrous and non-ferrous metals. In metal production, silica sand operates as a flux to lower the melting point and viscosity of the slags to make them more reactive and efficient. Lump silica is used either alone or in conjunction with lime to achieve the desired base/acid ratio required for purification. Construction Use-Silica sand comes from mines. Digged with heavy mining machineries. Then washed in fully automatic plant, so the clay and other impurities washed out fully. The mining operation is a delicate task because the sand has to be separated carefully in order to not carry too much coarse grains on it.

The Silica sand is very fine and whiter. It is also highly recommended for finishing works. The high silicon dioxide content (More than 98%) of our sand makes this product very demanded for these purposes. Micro- filling effect of Silica Sand reduces pores in concrete and provides better moisture resistivity and thus durability. Also saves cement.



We are giving below the standard specifications of silica sand available with us Ex-Stocks

GLASS GRADE

CHEMICAL SPECIFICATION OF GLASS GRADE SILICA SAND :



Source of Sand

Chemical Constituents ( % )



SiO2



Fe2O3



Al2O3



TiO2



CaO



MgO



LOI



Kutchh (Gujarat)

98.50

0.04

0.60

0.08

0.20

0.08

0.50

Min.

Max.

Max.

Max.

Max.

Max.

Max.

We can supply both Wet sand (5% moisture) and Dry sand (0.5% moisture)

GRANULOMETRY SPECIFICATION :

  • 24 BSS - 0.5 % Max.
  • 120 BSS - 5 % Max.

FOUNDRY GRADE

CHEMICAL SPECIFICATION OF FOUNDRY GRADE :

ELEMENT CONTAINS
SiO2 98.50% MIN.
Fe2O3 0.20% MAX.
Al2O3 0.70% MAX.
Cao 0.20% MAX.
TiO2 0.08% MAX.
MgO 0.08% MAX.
PH value 7 % MAX.
Moisture 0.5 % MAX. (Dry Sand)
  Clay 0.2 – 0.5 % MAX
(As per Customer requirement)
LOI 0.50% MAX.
  ADV (CC) 4 ML MAX (N/10 HCL - 50 Gms. Sand)

GRANULOMETRIC SPECIFICATION :

AFS 25 – 30 AFS 60 – 65
AFS 30 – 35 AFS 65 – 70
AFS 40 – 45 AFS 70 – 75
AFS 50 – 55 AFS 85 – 90
AFS 55 – 60 AFS 100 – 120

CHEMICAL SPECIFICATION OF CONSTRUCTION GRADE SILICA SAND

Material Description: Fine Aggregates (sand) Sample Qty : 20 Kg
Date of Sample Received: 16.03.2015 Sample Submitted by: Client
Testing Period: 17.03.2015 to 24.03.2015 Sample Source: ---
TEST Test Results Requirement as per IS
383-1970
Test Standards
1. Graduation Test IS 2386 (part 1) : 1963
(Reaffirmed 2007)
IS Sleve size % passing
10 mm 100.00 100
4.75 mm 99.35 90-100
2.36 mm 95.40 75-100
1.18 mm 72.65 55-90
600 micron 41.90 35-59
300 micron 2.65 8-30
150 micron 0.50 0-10
Zone of Sand || IS-383:1970
(Reaffirmed 2007)
Fineness Modules 2.88
Silt Content (%) 0.20 3 % Max IS 2386 (part 1) : 1963
(Reaffirmed 2007)
Absorption Value (%) 1.40 Not more than 2 % IS 2386 (part 3) : 1963
(Reaffirmed 2007)
Specific Gravity 2.59 - IS 2386 (part 3) : 1963
(Reaffirmed 2007)
Bulk Density
Loose Density (kg/Liter)
1.550 IS 2386 (part 3) : 1963
(Reaffirmed 2007)
Rodded Density (kg/Liter) 1.667
Soundness by Na2So4 (%) 3.60 10 % Max IS 2386 (part 5) : 1963
(Reaffirmed 2007)
Bulking of Sand (%) 13.79

MODE OF PACKING :

  • Loose loaded in
  • In 50 kgs. PP Bag. (One time used PP/HDPE bags).
  • In 1 MT Jumbo Bag. (One time used bags).
